Features
EASY TO REACH CONTROLS - FRONT CONTROLS
Front Controls are easy to reach.
INDICATES HOT SURFACE - INDICATOR LIGHT
Hot Surface Indicator light lets you know the surface is hot.
EASY CLEANUP
Smooth glass ceramic surface and dishwasher safe knobs make cleaning easy.
Specifications
General
Color
Black
Manufacturer Color
Black
Fuel Type
Electric
Type
Built-In
Cooktop
Burners/Elements
4
Power Output
• Element - Left Front: 1500 W
• Element - Left Rear: 1200 W
• Element - Right Front: 2000 W
• Element - Center: 2500 W
• Element - Left Rear: 1200 W
• Element - Right Front: 2000 W
• Element - Center: 2500 W
Burner/Element Size
• Element - Left Front: 7"
• Element - Left Rear: 6"
• Element - Right Front: 5"/8"
• Element - Center: 9"
• Element - Left Rear: 6"
• Element - Right Front: 5"/8"
• Element - Center: 9"
Elements
Smoothtop
Features
Digital Display
Yes
Additional Information
• Hot Surface Indicator Light
• Easy-to-Clean Glass, Ceramic Cooktop
• Dishwasher-Safe Knobs
• Easy-to-Clean Glass, Ceramic Cooktop
• Dishwasher-Safe Knobs
Electrical Information
Information
• 240 V
• 60 Hz
• 60 Hz
Certifications and Approvals
ADA Compliant
Yes
Information
Energy Star Certification
Dimensions
Class Width
30"
Width
30 inch(es) / 76.2 cm
Height
5.35 inch(es) / 13.6 cm
Depth
21.26 inch(es) / 54.0 cm
Weight
38.14 lb(s) / 17.3 kg
Additional Dimensions
Cooktop Cutout Dimensions: 28 3/8" x 5 1/8" x 19 7/16"
Shipping Dimensions
Width
34.25 inch(es) / 87 cm
Height
7.25 inch(es) / 18.42 cm
Depth
25.06 inch(es) / 63.65 cm
Weight
42.31 lb(s) / 19.19 kg
Warranty
Warranty
• One (1) Year All Parts and Labor
• Five (5) Years Parts Warranty for
• Glass Cooktop and Radiant Heater
• Five (5) Years Parts Warranty for
• Glass Cooktop and Radiant Heater
