Description
This 36-inch Bosch 500 Series induction cooktop features SpeedBoost®, 5 elements, 17 power levels for each cooking zone, and is Wi-Fi Enabled. The 500 Series induction cooktop is sleek in design and offers quick and even cooking results.
Features
SPEEDBOOST®
Sometimes you don't want to wait for a pot of water to boil. The SpeedBoost® function on Bosch induction cooktops adds even more power to speed up the cooking process.
RESTART
If you turn off the cooktop it saves the last selected setting for a short time. If the cooktop is switched of within a short time again the former settings are still available.
INDUCTION TECHNOLOGY
Induction technology directly heats your pots and pans instead of the cooktop itself for faster cooking and precise results.
Additional Features
CHILDLOCK
Bosch cooktops take safety up a notch. The ChildLock function prevents the cooktop from being accidentally switched on.
Specifications
General
Series Name
500 Series
Color
Black
Manufacturer Color
Black
Fuel Type
Electric Induction
Type
Built-In
Cooktop
Burners/Elements
5
Power Output
• Front Left: 1,800 W
• Front Left (in boost): 3,100 W
• Back Left: 1,800 W
• Back Left (in boost): 3,100 W
• Back Right: 1,400 W
• Back Right (in boost): 2,200 W
• Front Right: 2,200 W
• Front Right (in boost): 3,600 W
• Center: 2,200 / 2,600 / 3,300 W
• Center (in boost): 3,600 / 3,600 / 3,600 W
• Front Left (in boost): 3,100 W
• Back Left: 1,800 W
• Back Left (in boost): 3,100 W
• Back Right: 1,400 W
• Back Right (in boost): 2,200 W
• Front Right: 2,200 W
• Front Right (in boost): 3,600 W
• Center: 2,200 / 2,600 / 3,300 W
• Center (in boost): 3,600 / 3,600 / 3,600 W
Burner/Element Size
• Front Left: 6"
• Back Left: 9"
• Back Right: 11"
• Front Right: 6"
• Center: 9" / 11" /13" Triple-ring
• Back Left: 9"
• Back Right: 11"
• Front Right: 6"
• Center: 9" / 11" /13" Triple-ring
Elements
Smoothtop
Features
Technologies
• Induction Technology
• SpeedBoost®
• SpeedBoost®
Wi-Fi
Yes
Control Lock
Yes
Digital Display
Yes
Additional Information
• 17 power levels for each cooking zone
• SpeedBoost® - adds even more power to speed up the cooking process
• Quick Start: start straight away and select the desired cooking level.
• ReStart: if something boils over, the cooktop automatically turns itself off and saves the last selected setting
• Favorite button - one touch for your two most used cooking settings
• Automatic time limitation - will shut off your cooktop if the cooking zone has been in use for a long period of time without any changes
• SpeedBoost® - adds even more power to speed up the cooking process
• Quick Start: start straight away and select the desired cooking level.
• ReStart: if something boils over, the cooktop automatically turns itself off and saves the last selected setting
• Favorite button - one touch for your two most used cooking settings
• Automatic time limitation - will shut off your cooktop if the cooking zone has been in use for a long period of time without any changes
Electrical Information
Information
• 8,320 / 9,600 W
• 40 A
• 60 Hz
• 208 -240 V
• 40 A
• 60 Hz
• 208 -240 V
Certifications and Approvals
ADA Compliant
Yes
Information
Dekra US
Dimensions
Class Width
36"
Width
37 inch(es) / 93.98 cm
Height
4.25 inch(es) / 10.8 cm
Depth
21.25 inch(es) / 53.98 cm
Weight
50 lb(s) / 22.68 kg
Additional Dimensions
• Required cutout size (HxWxD): 4 1/8" x 34 7/8" x 20 1/4"
• Minimum distance from counter front: 2 1/4"
• Minimum distance from rear wall: 2"
• Minimum distance from counter front: 2 1/4"
• Minimum distance from rear wall: 2"
