Features
INFOLIGHT®
Bosch dishwashers are so quiet, you may forget they’re on. InfoLight® projects a red light onto the floor during the wash cycle that turns off when dishes are ready.
24/7 AQUASTOP®
The 24/7 AquaStop® system contains leaks through a precisely engineered tub and a solid molded base. Sensors detect leaks and pump out water, even when the system is off. So you never have to worry about leaks whether you're at home or away.
PRECISIONWASH® WITH POWERCONTROL™
Patented PowerControl™ spray arm enhances PrecisionWash® performance to target your dirtiest dishes with a deeper clean, no matter where you load them on the bottom rack. No more scrubbing, rinsing, or hand washing.
CRYSTALDRY™
Patented CrystalDry™ technology transforms moisture into heat up to 176°F to get dishes 60% drier,* so you can put away your plastic dishes immediately into the cupboard when the dishwasher is finished.
*Based on aggregate average drying performance of Bosch Dishwashers with CrystalDry on combined household load including plastics, glass, steel, and porcelain as compared to Bosch Dishwashers with PureDry. Drying performance may vary by dish type.
*Based on aggregate average drying performance of Bosch Dishwashers with CrystalDry on combined household load including plastics, glass, steel, and porcelain as compared to Bosch Dishwashers with PureDry. Drying performance may vary by dish type.
42 DBA
A range of technologies makes Bosch the quietest dishwasher brand in the U.S.* with impressively low decibel levels. For you, that means never having to wait until going to bed to run the dishwasher. *Based on an average of sound ratings of 24"" Full Size Stainless Steel Tub dishwashers contained in major brands websites. Major brands defined as TraQline Top 5 Market Share December 2021.
FLEXIBLE 3RD RACK
Our Flexible 3rd Rack features expandable wings that easily lower to accommodate more of your deeper items while adjustable tines let you customize the rack’s loading space to fit awkward bulky items.
RACKMATIC®
The RackMatic middle rack easily adjusts to three different heights and up to 9 separate rack positions, allowing taller items like stemware to fit in the middle rack while leaving room for pots and pans below.
Additional Features
HOME CONNECT™.
Smart Cycle takes the guesswork out of cycle selection by quickly helping you identify and save the best program combination for your needs. Now you can clean smarter, not harder – only with Home Connect.
EASYGLIDE™ RACK SYSTEM
Quality materials and design make the EasyGlide rack system smooth, so you get an effortless feel with every pull--even when the rack is fully loaded.
Specifications
General
Series Name
800
Type
Built-In
Color
Panel Ready
Place Settings
16
Tub Material
Stainless Steel
Silence Rating
42 dB
Cycle Information
Number of Cycles
8
Wash Cycles
5 + 3 additional in Home Connect
Options
4 + 2 additional in Home Connect
Features
Technologies
• PowerControl™ with PrecisionWash®
• CrystalDry™
• Rackmatic®
• Leak protection system: 24/7 AquaStop®
• Home Connect® (WiFi enabled)
• InfoLight®
• CrystalDry™
• Rackmatic®
• Leak protection system: 24/7 AquaStop®
• Home Connect® (WiFi enabled)
• InfoLight®
3rd Rack System
Yes
Silverware Basket
Yes
Wi-Fi
Yes
Additional Information
• Concealed water heating element
• Five-level wash
• Five-level wash
Electrical Information
Information
• Total annual energy consumption: 239 kWh
• 1440 W
• 12 Amps
• 120 V
• 60 Hz
• 1440 W
• 12 Amps
• 120 V
• 60 Hz
Certifications and Approvals
Energy Star Certified
Yes
NSF® Certified
Yes
Accessories
Optional
• Junction Box SMZPCJB1UC
• Junction Box + Supply Hose Kit SMZ3IN1UC
• Bosch Dishwasher Water Supply Hose SMZSH002UC
• Drain Hose Extension Kit SGZ1010UC
• Dishwasher Accessory Kit SMZ5000
• Anti-Tarnish Silverware Cassette SMZ5002UC
• Edge Protector + Power Cord Clip Install Kit SMZEPCC1UC
• Junction Box + Supply Hose Kit SMZ3IN1UC
• Bosch Dishwasher Water Supply Hose SMZSH002UC
• Drain Hose Extension Kit SGZ1010UC
• Dishwasher Accessory Kit SMZ5000
• Anti-Tarnish Silverware Cassette SMZ5002UC
• Edge Protector + Power Cord Clip Install Kit SMZEPCC1UC
Dimensions
Class Width
24"
Width
23.54 inch(es) / 59.8 cm
Height (Min.)
33.86 inch(es) / 86.0 cm
Depth (Without Handle)
23.03 inch(es) / 58.5 cm
UPC
UPC#
825225966043
