Features
AQUASTOP® PLUS.
A leak is the last thing you want to happen to your kitchen floors. AquaStop® Plus features additional sensors to ensure that any potential leaks are quickly detected and contained.
3RD RACK
The 3rd rack provides extra space for flatware, large utensils and measuring cups. Its V shape leaves room below for tall items. *Compared to a Bosch dishwasher with 2 racks
Additional Features
HOME CONNECT™.
Smart Cycle takes the guesswork out of cycle selection by quickly helping you identify and save the best program combination for your needs. Now you can clean smarter, not harder – only with Home Connect.
Specifications
General
Series Name
300 Series
Type
Built-In
Color
Stainless Steel
Manufacturer Color
Stainless Steel
Place Settings
10
Tub Material
Stainless Steel
Silence Rating
46 dB
Cycle Information
Number of Cycles
5
Options
5
Features
Technologies
• PrecisionWash® Wash System
• RackMatic®
• 24/7 AquaStop® Plus Leak Protection System
• Home Connect™ (Wi-Fi enabled)
• RackMatic®
• 24/7 AquaStop® Plus Leak Protection System
• Home Connect™ (Wi-Fi enabled)
Delay Start Information
24 Hours
3rd Rack System
Yes
Control Lock
Yes
Wi-Fi
Yes
Additional Information
• Special Program: Machine Care
• Concealed Water Heating Element
• Five-Level Wash
• Concealed Water Heating Element
• Five-Level Wash
Electrical Information
Information
• 240 kWh/Year
• 1440 W
• 12 A
• 60 Hz
• 1440 W
• 12 A
• 60 Hz
Certifications and Approvals
Energy Star Certified
Yes
ADA Compliant
Yes
Accessories
Optional
• Junction Box SMZPCJB1UC
• Dishwasher Drain Hose Extension SGZ1010UC
• Accessory Kit SMZ5000
• Hinge for 4" Toekick Height Installation SMZ5003
• Edge Protector + Power Cord Clip Install Kit SMZEPCC1UC
• Dishwasher Drain Hose Extension SGZ1010UC
• Accessory Kit SMZ5000
• Hinge for 4" Toekick Height Installation SMZ5003
• Edge Protector + Power Cord Clip Install Kit SMZEPCC1UC
Dimensions
Class Width
18"
Width
17.62 inch(es) / 44.76 cm
Height (Min.)
32.06 inch(es) / 81.43 cm
Depth (Without Handle)
22.56 inch(es) / 57.30 cm
Weight
72 lb(s) / 32.66 kg
Additional Dimensions
• Required cutout size (HxWxD): 32 1/8" x 17 3/4" x 24"
• Power cord full length 67"
• Power cord install length from edge of unit when facing the door: Left – 51", Right – 51"
• Minimum water pressure 7: lb/sin
• Length inlet hose: 65"
• Length outlet hose: 80 5/8"
• Power cord full length 67"
• Power cord install length from edge of unit when facing the door: Left – 51", Right – 51"
• Minimum water pressure 7: lb/sin
• Length inlet hose: 65"
• Length outlet hose: 80 5/8"
UPC
UPC#
825225970545
